Fusion 101A Syringe Pump
Item No: 10071
Powered by Bioz$899.00$1,100.00
In Stock - Same Day Shipping
System Overview
Chemyx Fusion 101A is a programmable infusion-only syringe pump that performs the most basic precision dispensing activities. This syringe pump comes with standard infuse mode and multi-step programmable mode. It also has an RS232 and USB port that allows the pump to be controlled by a computer. The programmable infusion pump can be used for mass spectrometry calibration, synthetic chemistry, electro-spinning, drug infusion, and ESI microliter injections. The upgrade of this model is Fusion100-X.
Standard Features:
- Graphic LCD interface
- RS232 port for computer control
- Integrated syringe dimensions library
- Selectable rate units: μl/hr, μl/min, ml/hr, ml/min
- Stall detection with audible alarm
- Silent operation
- Accommodates any syringe: glass, plastic, and microsyringes
- 1-Year Limited* Warranty
Technical Specifications:
| Mode | Infuse Only |
| Accuracy | ± < 0.35% |
| Reproducibility | ± < 0.05% |
| Syringe Size (Min/Max) | 10µL to 50mL |
| Syringe Type | Plastic and Glass |
| Syringe Flow Rates | See Syringe Library for Min & Max Flow Rates |
| Minimum Flow Rate | 0.0001 µL/min (with 0.5µL syringe) |
| Maximum Flow Rate | 38 mL/min (with 30mL syringe) |
| Linear Force | 26lb (11.8kg) |
| Display | 4.3 inch LCD Screen |
| Connectivity | RS232 and USB-B Ports |
| System Dimensions | 9.5 x 6.8 x 4.4 inches (24 x 17 x 11 cm) |
| Power | 110/220 VAC |
| Weight | 7lbs (3kg) |
| Motor Drive | 0.9˚ Stepper Motor with Micro-stepping |
| Step Resolution | 0.198 µm/step |
| Operating Temperature | 4°C to 40°C (40°F to 104°F) |
| Regulatory Compliance | CE, RoHS, REACH, FCC, IC |
